Fan, WRF 230/230

Fan, WRF 230/230
Offer Type / Ergom index Min. order quantity [uom] Qty in package Unit of measure [uom] Catalogue price net per uom Quantity [uom]
WRF 230/230 R37RC-02010100701 1 1 pcs. Price on request
Sum:
— net
VAT:
23%
Logistic data Ergom index EAN Stock availability Net weight Delivery time
WRF 230/230 R37RC-02010100701
  • 5900003360901 1 SZT.
 stockable Warehouse products are shipped from stock; the remaining ones are made to order. ~ 1,300 kg 24h Dotyczy dni roboczych. Ostateczny czas realizacji będzie podany w potwierdzeniu zamówienia.

Features and benefits

No data

Product description

WRF 230/230 FAN

Technical data

Certyfikaty normy

Stopień ochrony IP43, according to IEC 60529
Normy EN 55014-1:2004; EN 55014-2:1999 – AC and DC fans. EN 60335-2-80:2007; EN 60335-1:2004+EN 60335-1:2004/ A1:2005, EN 60335-1:2004/A2:2006 – AC fans.

Dane mechaniczne

Colour RAL 7035
Housing material filter: self-extinguishing plastic in grey colour fan: aluminium alloy, plastic
Filter cartridge material self-extinguishing, nylon unwoven fabric
Fan blade material plastic
Noise level [dB] 54
Motor type AC inductive
Operating temperature [°C] -10 ÷ +55
Efficiency [m³/h] 230
Efficiency with filter [м³/h] 205
Efficiency, free flow [m³/h] 230
Mounting hole [mm] 224 x 224

Dane elektryczne

Rated power [W] 33
Rated voltage [V AC] 230, 50 Hz
Rated current [A AC] 0,28

Guide

No data

Accessories and sets

No data

Knowledge

No data

Downloads

Type Name Language Updated at Size File type
Catalog card ERGOM_Wentylator_WRF_230_230_EN.pdf EN 15-05-2025 355.27 KB PDF Download
Catalog card ERGOM_Wentylator_WRF_230_230_PL.pdf PL 15-05-2025 350.47 KB PDF Download
