Reducer, MDR...PG/PG type

Reducer, MDR...PG/PG type

Main data of the product series

Product name
Reducer, MDR...PG/PG type
Category
Metal accessories
Material
nickel-plated brass
Note!
Nuts and reducer seals have to be ordered separately.

Features and benefits

Product description

-

Offer

Name Ergom index / your designation Min. order quantity [uom] Qty in package Unit of measure [uom] Catalogue price net per uom Quantity [uom]
MDR 9/7 E03DK-04060100103 10 10 pcs. Price on request
MDR 11/7 E03DK-04060100203 10 10 pcs. Price on request
MDR 11/9 E03DK-04060100303 10 10 pcs. Price on request
MDR 13/9 E03DK-04060100403 10 10 pcs. Price on request
MDR 13/11 E03DK-04060100503 10 10 pcs. Price on request
MDR 16/9 E03DK-04060100603 10 10 pcs. Price on request
MDR 16/11 E03DK-04060100703 10 10 pcs. Price on request
MDR 16/13 E03DK-04060100803 10 10 pcs. Price on request
MDR 21/9 E03DK-04060100903 10 10 pcs. Price on request
MDR 21/11 E03DK-04060101003 10 10 pcs. Price on request
MDR 21/13 E03DK-04060101103 10 10 pcs. Price on request
MDR 21/16 E03DK-04060101203 10 10 pcs. Price on request
MDR 29/16 E03DK-04060101303 10 10 pcs. Price on request
MDR 29/21 E03DK-04060101403 10 10 pcs. Price on request
MDR 36/21 E03DK-04060101503 10 10 pcs. Price on request
MDR 36/29 E03DK-04060101603 10 10 pcs. Price on request
MDR 42/29 E03DK-04060101703 1 1 pcs. Price on request
MDR 42/36 E03DK-04060101803 1 1 pcs. Price on request
MDR 48/36 E03DK-04060102003 1 1 pcs. Price on request
MDR 48/42 E03DK-04060102103 1 1 pcs. Price on request

Selected lines: 0

Technical data

General data

Material nickel-plated brass
Name Reduction, PG1/PG2 E L For spanner A
MDR 9/7 PG9 / PG7 5 2,0 16
MDR 11/7 PG11 / PG7 6 2,0 20
MDR 11/9 PG11 / PG9 6 2,0 20
MDR 13/9 PG13,5 / PG9 6 2,5 22
MDR 13/11 PG13,5 / PG11 6 2,5 22
MDR 16/9 PG16 / PG9 6 2,5 24
MDR 16/11 PG16 / PG11 6 2,5 24
MDR 16/13 PG16 / PG13,5 6 2,5 24
MDR 21/9 PG21 / PG9 7 3,0 30
MDR 21/11 PG21 / PG11 7 3,0 30
MDR 21/13 PG21 / PG13,5 7 3,0 30
MDR 21/16 PG21 / PG16 7 3,0 30
MDR 29/16 PG29 / PG16 8 3,0 40
MDR 29/21 PG29 / PG21 8 3,0 38
MDR 36/21 PG36 / PG21 8 3,5 48
MDR 36/29 PG36 / PG29 8 3,5 48
MDR 42/29 PG42 / PG29 10 4,0 58
MDR 42/36 PG42 / PG36 10 4,0 58
MDR 48/36 PG48 / PG36 10 4,0 64
MDR 48/42 PG48 / PG42 10 4,0 64

Guide

Reducer, MDR...PG/PG type

Knowledge

No data

Downloads

Type Name Language Updated at Size File type
Catalog card ERGOM_Redukcja_typu_MDR_PG_PG_EN.pdf EN 14-05-2025 195.55 KB PDF Download
Catalog card ERGOM_Redukcja_typu_MDR_PG_PG_PL.pdf PL 14-05-2025 235.41 KB PDF Download
