Insulated female push-on connectors in heat-shrink insulation, NIT type

Insulated female push-on connectors in heat-shrink insulation, NIT type

Main data of the product series

Product name
Insulated female push-on connectors in heat-shrink insulation, NIT type
Category
For double crimping (with copper sleeve)
Surface
tin-plated
Material
brass
Insulation
heat-shrink sleeve
Operating temperature [°C]
-55 ÷ +105

Features and benefits

Product description

-

Offer

Name Ergom index / your designation Min. order quantity [uom] Qty in package Unit of measure [uom] Catalogue price net per uom Quantity [uom]
NIT 6,3-1/0,8 E09KO-02070400201 1 100 pkt. Price on request
NIT 6,3-2,5/0,8 E09KO-02070400301 1 100 pkt. Price on request
NIT 6,3-6/0,8 E09KO-02070400401 1 100 pkt. Price on request

Selected lines: 0

Technical data

General data

Insulation heat-shrink sleeve
Material brass
Surface tin-plated
Operating temperature [°C] -55 ÷ +105
Shrink temperature [°C] > 120
Size 6,3x0,8
L2 7,2
Name Insulation colour d D L1 L3 Cross-section [mm²]
NIT 6,3-1/0,8 red 1,7 4,8 30 21 0,75 - 1
NIT 6,3-2,5/0,8 blue 2,3 5,8 30 21 1,5 - 2,5
NIT 6,3-6/0,8 yellow 3,4 6,8 32 25 4 - 6

Guide

No data

Knowledge

No data

Downloads

Type Name Language Updated at Size File type
Catalog card ERGOM_Nasuwki_konektorowe_izolowane_w_izolacji_termokurczliwej_typ_NIT_EN.pdf EN 04-07-2025 192.46 KB PDF Download
Catalog card ERGOM_Nasuwki_konektorowe_izolowane_w_izolacji_termokurczliwej_typ_NIT_PL.pdf PL 04-07-2025 213.02 KB PDF Download
