Edge holder cable ties, EKR type

Edge holder cable ties, EKR type

Main data of the product series

Product name
Edge holder cable ties, EKR type
Category
Mated with cable ties
Material
polyamide 6.6 (thermally stabilized)
Operating temperature [°C]
-40 ÷ +85
Flammability class
HB wg UL 94

Features and benefits

Product description

-

Offer

Name Ergom index / your designation Min. order quantity [uom] Qty in package Unit of measure [uom] Catalogue price net per uom Quantity [uom]
EKR 1B E01EM-01110600101 1 100 pkt. Price on request
EKR 1B E01EM-01110600103 1 10 pkt. Price on request
EKR 1G E01EM-01110600201 1 100 pkt. Price on request
EKR 1G E01EM-01110600203 1 10 pkt. Price on request
EKR 3G E01EM-01110600301 1 100 pkt. Price on request
EKR 3G E01EM-01110600303 1 10 pkt. Price on request

Selected lines: 0

Technical data

General data

Material polyamide 6.6 (thermally stabilized)
UV Resistance yes
Colour Black
Operating temperature [°C] -40 ÷ +85
Cable position relative to the profile along or crosswise
Klasa palności HB wg UL 94
Name Cable tie installation Profile thickness [mm] Design G L H
EKR 1B side of holder 1-3 A 2,9 14 12
EKR 1G top of holder 1-3 B 2,9 14 12
EKR 3G top of holder 3-6 C 5,3 14,5 14

Guide

Edge holder cable ties, EKR type

Knowledge

No data

Downloads

Type Name Language Updated at Size File type
Catalog card ERGOM_Uchwyty_krawedziowe_do_tasm_kablowych_EKR_EN.pdf EN 12-08-2025 357.58 KB PDF Download
Catalog card ERGOM_Uchwyty_krawedziowe_do_tasm_kablowych_EKR_PL.pdf PL 12-08-2025 351.44 KB PDF Download
