Cable plate set, FL 21Z...

Cable plate set, FL 21Z...

Main data of the product series

Product name: Cable plate set, FL 21Z...
Category: FL 21 membrane cable plate system
Operating temp. [°C]: -20 ÷ +125
Material: polypropylene reinforced with glass fibre and TPE elastomer, halogen-free

Features and benefits

Product description

-

Offer

Name	Ergom index / your designation	Min. order quantity [uom]	Qty in package	Unit of measure [uom]	Catalogue price net per uom	Quantity [uom]
FL 21Z1	R30RS-04070000101	10	10	pcs.	Price on request
FL 21Z2	R30RS-04070000201	10	10	pcs.	Price on request
FL 21Z3	R30RS-04070000301	10	10	pcs.	Price on request

Selected lines: 0

Technical data

General data

Material	polypropylene reinforced with glass fibre and TPE elastomer, halogen-free
Operating temp. [°C]	-20 ÷ +125
Assembly	Set, ZNFL type (bolts + nuts)
Stopień ochrony	IP65 (with and without cables installed)
Normy	EN 60529:1991+A1; EN 60670-1:2005

Name	Cable diameter [mm]
FL 21Z1	2x8÷17 mm, 2x5÷10 mm (M16), 2x6÷13 mm, 20x4÷10 mm
FL 21Z2	2x8÷17 mm, 2x6÷13 mm, 30x4÷10 mm
FL 21Z3	18x7÷14 mm, 10x4÷10 mm

Guide

No data

Knowledge

No data

Downloads

Type	Name	Language	Updated at	Size	File type
Catalog card	ERGOM_Zestawy_plyt_kablowych_FL_21_EN.pdf	EN	15-05-2025	176.23 KB	PDF	Download
Catalog card	ERGOM_Zestawy_plyt_kablowych_FL_21_PL.pdf	PL	15-05-2025	189.13 KB	PDF	Download
